SKU: 928364715462-EN1
$100.57 $93.99
Guaranteed secure & safe checkout.
Data sheet PDF
Product Description
XVR1B08-I
8CH Penta-brid 1080N/720P Cooper 1U 1HDD WizSense Digital Video Recorder
> 4-channel SMD Plus for analog channels which allows the device to trigger accurate alarms for humans and vehicles.
> 8-channel AI Coding saves on storage and bandwidth while maintaining the details of targets in videos.
> Supports HDCVI, AHD, TVI, CVBS and IP video input.
> Supports up to 10-channel IP camera input and each channel can be up to 6 MP. The incoming bandwidth reaches 40 Mbps.
> Smart H.265+ and H.265 dual-stream video compression.
Specifications
System | |
Main Processor | Industrial-grade processor |
Operating System | Embedded Linux |
Operating Interface | Web; Local GUI |
SMD Plus | |
SMD Plus by Recorder | 4 channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
Audio and Video | |
Analog Camera Input | 8 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect |
Camera Input | 1. CVI: 1080p@25/30 fps; 720p@25/30 fps. 2. TVI: 1080p@25/30 fps; 720p@25/30 fps. 3. AHD: 1080p@25/30 fps; 720p@25/30 fps. |
IP Camera Input | Up to 10 channels of IPC access 2 IP channels by default + 8 channels (analog channels are converted to IP channels) Incoming bandwidth: 40 Mbps, recording bandwidth: 40 Mbps and outgoing bandwidth: 40 Mbps *After IP extension is enabled, the AI Function (SMD) will be disabled. |
Encoding Capacity | Main stream: the 1st channel 1080N/720p@(1 fps?25/30 fps), others 1080N/720p@(1 fps?15 fps); 960H/D1/CIF@(1 fps?25/30 fps) Sub stream: CIF@(1 fps?7 fps) |
Dual-stream | Yes |
Video Bit Rate | 32 kbps?4096 kbps |
Audio Sampling | 8 kHz, 16 bit |
Audio Bit Rate | 64 kbps |
Video Output | 1 HDMI, 1 VGA HDMI: 1920 ? 1080, 1280 ? 1024, 1280 ? 720 VGA: 1920 ? 1080, 1280 ? 1024, 1280 ? 720 |
Multi-screen Display | When IP extension mode not enabled: 1/4/8/9 When IP extension mode enabled: 1/4/8/9/16 |
Third-party Camera Access | Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF |
Compression Standard | |
Video Compression | AI Coding; Smart H.265+; H.265; Smart H.264+; H.264 |
Audio Compression | G.711a; G.711u; PCM |
Network | |
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.) |
Mobile Phone Access | iOS; Android |
Interoperability | ONVIF 22.12 (Profile T; Profile S; Profile G); CGI; SDK |
Browser | Chrome; IE; Safari; Edge; Firefox |
Recording Playback | |
Record Mode | General; alarm; motion detection |
Recording Playback | 1/4/9 |
Backup Method | USB device and network |
Playback Mode | Instant playback; general playback; event playback; tag playback; smart playback |
Alarm | |
General Alarm | Motion detection; HDCVI alarm; camera external alarm; network alarm; PIR alarm |
Anomaly Alarm | Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline |
Intelligent Alarm | SMD Plus |
Alarm Linkage | Record; snapshot (panoramic); IPC external alarm output; audio; buzzer; log; preset; email |
Ports | |
Audio Input | 1-channel RCA 8-channel BNC (Coaxial Audio) |
Audio Output | 1-channel RCA |
Two-way Talk | Yes (share the same audio input with the first channel) |
Disk Interface | 1 SATA port, up to 6 TB. This limit varies depending on the environment temperature. |
USB | 2 (2 rear USB 2.0 ports) |
HDMI | 1 |
VGA | 1 |
Network Port | 1 (10/100 Mbps Ethernet port, RJ-45) |
General | |
Power Supply | 12 VDC, 1.5 A |
Power Consumption | <7 W (without HDD) |
Net Weight | 0.56 kg (1.24 lb) |
Gross Weight | 0.96 kg (2.10 lb) |
Product Dimensions | 197.0 mm ? 202.9 mm ? 41.5 mm (7.76" ? 7.99" ? 1.63") (W ? D ? H) |
Packaging Dimensions | 332.0 mm ? 64.0 mm ? 240.0 mm (13.07" ? 2.52" ? 9.45") (W ? D ? H) |
Operating Temperature | ?10 ?C to +45 ?C (+14 ?F to +113 ?F) |
Storage Temperature | ?20 ?C to +60 ?C (?4 ?F to +140 ?F) |
Operating Humidity | 10%?90% (RH), non-condensing |
Installation | Desktop |
Certifications | CE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014 FCC: 47 CFR Part 15, Subpart B |
Record video continuously—24 hours a day, 7 days a week—without interruptionComplete Coverage: Never miss an event, even during quiet hours. Reliable Evidence: Essential for reviewing incidents with accurate timelines. Peace of Mind: Know your property is monitored at all times. Ideal for High-Risk Areas: Great for businesses, warehouses, or remote properties that require constant surveillance. Perfect for anyone needing maximum security and a full visual record of all activity.
Mobile app access so you can monitor your home remotely which means you feel in control no matter where you are—whether you're at work, on vacation, or just out for dinner, your home is always just a tap away.
