Hikvision 32CH NVR DS-9632NI-I8 UP TO 12MP RESOLUTION 8 SATA PRO LINE

Description

Hikvision 32CH NVR DS-9632NI-I8 UP TO 12MP RESOLUTION 8 SATA PRO LINE


This listing includes:

  • ¬†(1) HARD DRIVE OPTION:¬†NO HARD DRIVE;8TB;16TB;32TB;48TB;64TB;80TB
  • (1) NETWORK RECORDER: DS-9632NI-I8


DS-9632NI-I8  view data sheet

32ch 2U 4K NVR

  • Up to 32ch IP cameras can be connected
  • Up to 12 MP high-definition live view, storage and playback
  • Up to 320 Mbps (or 200 Mbps when RAID is enabled) high incoming bandwidth ensures IP cameras can be connected
  • 2 HDMI (different source) and 2 VGA (different source) interfaces
  • 8 HDD can be used for continuous video recording
  • Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera/fisheye camera
  • Advanced streaming technology enables smooth live view in poor network conditions
  • Supports RAID 0, 1, 5, 6, 10 and N+1 hot spare for even more reliable data storage, effectively avoids data loss risks

Hikvision 32CH NVR DS-9632NI-I8 UP TO 12MP RESOLUTION 8 SATA PRO LINE

Product form

SKU: 669864715462-EN1

$1,202.24 $1,144.99

Out of stock

  • Shipped today? Order within: Sep 11, 2025 15:00:00 -0400
    • Guaranteed secure & safe checkout.

      paypal

    Description

    Hikvision 32CH NVR DS-9632NI-I8 UP TO 12MP RESOLUTION 8 SATA PRO LINE


    This listing includes:

    • ¬†(1) HARD DRIVE OPTION:¬†NO HARD DRIVE;8TB;16TB;32TB;48TB;64TB;80TB
    • (1) NETWORK RECORDER: DS-9632NI-I8


    DS-9632NI-I8  view data sheet

    32ch 2U 4K NVR

    • Up to 32ch IP cameras can be connected
    • Up to 12 MP high-definition live view, storage and playback
    • Up to 320 Mbps (or 200 Mbps when RAID is enabled) high incoming bandwidth ensures IP cameras can be connected
    • 2 HDMI (different source) and 2 VGA (different source) interfaces
    • 8 HDD can be used for continuous video recording
    • Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera/fisheye camera
    • Advanced streaming technology enables smooth live view in poor network conditions
    • Supports RAID 0, 1, 5, 6, 10 and N+1 hot spare for even more reliable data storage, effectively avoids data loss risks
    !

    Recommended replacement

    We recommend these compatible/updated alternatives:

    Why This Matters.

    Advanced Security, Made Simple.



    Record video continuously 24/7!

    Record video continuously 24/7!

    Record video continuously—24 hours a day, 7 days a week—without interruptionComplete Coverage: Never miss an event, even during quiet hours. Reliable Evidence: Essential for reviewing incidents with accurate timelines. Peace of Mind: Know your property is monitored at all times. Ideal for High-Risk Areas: Great for businesses, warehouses, or remote properties that require constant surveillance. Perfect for anyone needing maximum security and a full visual record of all activity.

    Total Control, Anywhere

    Total Control, Anywhere

    Mobile app access so you can monitor your home remotely which means you feel in control no matter where you are—whether you're at work, on vacation, or just out for dinner, your home is always just a tap away.

    Technical Specifications

    Data sheet PDF

    Product Description

    32ch 2U 4K NVR

    • Up to 32ch IP cameras can be connected
    • Up to 12 MP high-definition live view, storage and playback
    • Up to 320 Mbps (or 200 Mbps when RAID is enabled) high incoming bandwidth ensures IP cameras can be connected
    • 2 HDMI (different source) and 2 VGA (different source) interfaces
    • 8 HDD can be used for continuous video recording
    • Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera/fisheye camera
    • Advanced streaming technology enables smooth live view in poor network conditions
    • Supports RAID 0, 1, 5, 6, 10 and N+1 hot spare for even more reliable data storage, effectively avoids data loss risks

    Specification

      • Video And Audio
      • IP Video Input

        32ch

        Up to 12 MP resolution

        *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. For DS-9632NI-I8, when ultra HD resolution mode is enabled, it will reduce the IP video input to 24ch.

      • Incoming Bandwidth320 Mbps
      • Outgoing Bandwidth256 Mbps
      • Incoming Bandwidth (RAID Mode)200 Mbps
      • Outgoing Bandwidth (RAID Mode)200 Mbps
      • HDMI 1 Output4K (3840 ? 2160)/60Hz, 4K (3840 ? 2160)/30Hz, 1920 ? 1080/60Hz, 1600 ? 1200/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz
      • HDMI 2 Output1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz
      • VGA 1 Output1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz
      • VGA 2 Output1920 ? 1080/60Hz, 1280 ? 1024/60Hz, 1280 ? 720/60Hz, 1024 ? 768/60Hz
      • Video Output Mode

        HDMI 1 and VGA 1 provide simultaneous video output, and work as the main output;

        HDMI 2 and VGA 2 provide simultaneous video output, and work as the auxiliary output

      • CVBS Output1-ch, BNC (1.0 Vp-p, 75 ?), resolution: PAL: 704 ? 576, NTSC: 704 ? 480
      • Audio Output2-ch, RCA (Linear, 1 K?)
      • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 K?, using the audio input)
      • Decoding
      • Decoding FormatH.265+/H.265/H.264+/H.264/MPEG4
      • Recording Resolution

        32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

        *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. For DS-9632NI-I8, when ultra HD resolution mode is enabled, it will reduce the IP video input to 24ch.

      • Synchronous Playback16ch
      • Decoding Capability1-ch@32 MP (30 fps)/2-ch@12 MP (20fps)/4ch@8 MP (25fps)/8ch@4 MP (30fps)/16ch@1080p (30fps)
      • Dual-Stream RecordingSupport
      • Stream TypeVideo, Video & Audio
      • Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM
      • Network
      • Remote Connection128
      • Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP?, HTTP, HTTPS
      • Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
      • RAID
      • RAID TypeRAID0, RAID1, RAID5, RAID6, and RAID10 (at least 4 TB for each HDD)
      • Auxiliary Interface
      • Serial Interface1 RS-485 (full-duplex), 1 RS-232, 1 keyboard
      • SATA8 SATA interfaces supporting hot-plug
      • ESATA1 eSATA interface
      • CapacityUp to 10TB capacity for each disk
      • Alarm In/Out16/4
      • USB InterfaceFront panel: 2 ? USB 2.0; Rear panel: 1 ? USB 3.0
      • General
      • Power Supply100 to 240 VAC, 50 to 60 Hz
      • Consumption? 30 W
      • Working Temperature-10 ?C to 55 ?C (14 ?F to 131 ?F)
      • Working Humidity10% to 90%
      • Chassis2U chassis
      • Dimension (W ? D ? H)445 ? 465 ? 92 mm ( 17.5"? 18.3" ? 3.6")
      • Weight? 10 kg (22 lb)
      • Certification
      • FCCPart 15 Subpart B, ANSI C63.4-2014
      • CEEN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
