Image Sensor |
1/3" Progressive Scan CMOS |
Max. Resolution |
2560 × 1440 |
Shutter Time |
1/3 s to 1/100,000 s |
Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
Day & Night |
IR cut filter |
Angle Adjustment |
Pan: 0°–355°; Tilt: 0°–75°; Rotate: 0°–355° |
Lens Type |
Fixed, 2.8 mm or 4 mm; M12; F1.6 |
Field of View |
2.8 mm: H 98° / V 54° / D 114° 4 mm: H 78° / V 42° / D 93° |
DORI (2.8 mm) |
D: 63 m, O: 25 m, R: 12 m, I: 6 m |
DORI (4 mm) |
D: 78 m, O: 31 m, R: 15 m, I: 7 m |
Supplement Light Type |
IR, White Light |
Supplement Light Range |
Up to 30 m |
Smart Supplement Light |
Yes |
IR Wavelength |
850 nm |
Main Stream |
50 Hz: 20 fps (2560×1440); 25 fps (1920×1080, 1280×720) 60 Hz: 20 fps (2560×1440); 24 fps (1920×1080, 1280×720) |
Sub‑Stream |
50 Hz: 25 fps (1280×720, 640×480, 640×360) 60 Hz: 24 fps (1280×720, 640×480, 640×360) |
Video Compression |
Main: H.265+/H.265/H.264+/H.264; Sub: H.265/H.264/MJPEG |
Video Bit Rate |
32 Kbps to 8 Mbps |
H.264 Type |
Baseline, Main, High Profile |
H.265 Type |
Main Profile |
Bit Rate Control |
CBR, VBR |
ROI |
1 fixed region (main stream) |
Audio Type |
Mono sound; Environment noise filtering |
Audio Sampling Rate |
8 kHz / 16 kHz |
Audio Compression |
G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / AAC‑LC |
Audio Bit Rate |
64 Kbps (G.711u) / 64 Kbps (G.711a) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32–160 Kbps (MP2L2) / 16–64 Kbps (AAC‑LC) |
Security |
Password protection; watermark; HTTP basic/digest; WSSE; ONVIF auth; security audit log; host (MAC) auth |
Simultaneous Live View |
Up to 6 channels |
API |
ONVIF (Profile S/T/G*), ISAPI, SDK (*Profile G only on -F) |
Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
Users |
Up to 32 (admin / operator / user) |
Client / Browser |
iVMS‑4200, Hik‑Connect / IE10–11 (plug‑in), Chrome 57+, Firefox 52+ (local) |
WDR |
120 dB |
SNR |
≥ 52 dB |
Day/Night Switch |
Day, Night, Auto, Schedule |
Image Enhancement |
BLC, HLC, 3D DNR |
Image Settings |
Rotate; saturation; brightness; contrast; sharpness; gain; white balance (via client/web) |
Privacy Mask |
4 programmable polygon masks |
Ethernet |
1× RJ45 10/100M self‑adaptive |
On‑Board Storage (‑F) |
microSD/SDHC/SDXC up to 256 GB |
Built‑in Mic |
Yes |
Reset Key |
‑F: Yes |
Events |
Motion detection (by target type: human/vehicle), video‑tampering, exception |
Linkage |
Upload to FTP/memory card (‑F), email, notify center, trigger recording (‑F), trigger capture |
Power |
12 VDC ±25% (0.5 A, max 6 W, Ø 5.5 mm coaxial, reverse‑polarity), PoE IEEE 802.3af Class 3 (max 7.5 W) |
Material |
Metal & Plastic |
Dimensions |
Ø 121.4 mm × 97.7 mm (Ø 4.8" × 3.8") |
Weight |
Approx. 550 g (1.2 lb.) |
Package Dimensions / Weight |
150 × 150 × 141 mm (5.9" × 5.9" × 5.6"); ~800 g (1.8 lb.) |
Storage / Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), ≤95% RH (non‑condensing) |
Language |
English, Ukrainian |
General Functions |
Heartbeat, anti‑banding, mirror, password protection, password reset via email |
Certifications |
EMC: FCC, CE‑EMC, RCM, IC; Safety: UL, CB, CE‑LVD, BIS; Environment: CE‑RoHS, WEEE, REACH |
Protection |
IP67; IK08 |
