Hikvision iDS-2CD8A86G0-XZS 8MP Dual-Lens AI LPR IP67 IK10 Bullet Camera
Hikvision iDS-2CD8A86G0-XZS 8MP Dual-Lens AI LPR IP67 IK10 Bullet Camera
Hybrid Light
Motorized
Hurry up, only 10 items left in stock.
products.product.pickup_availabilities
Description
Description
Hikvision iDS-2CD8A86G0-XZS 8MP DeepinView Dual-Lens AI Bullet Camera
When you need both wide-area coverage and crystal-clear detail, most cameras force you to choose. The iDS-2CD8A86G0-XZS solves that with a powerful dual-channel design—one lens captures sharp 8 MP detail while the second provides panoramic awareness. Add deep-learning analytics, license plate recognition, and ultra-low-light performance, and you’re not just recording video—you’re capturing usable evidence. This camera is built for environments where clarity, intelligence, and reliability directly impact security decisions.
Why Buyers Choose This Model
Buyers choose this model when they want to reduce blind spots without doubling hardware. Instead of installing separate overview and zoom cameras, this single device handles both tasks at once. With built-in AI detection and high-accuracy license plate recognition, it doesn’t just capture footage—it helps identify what actually matters. For security teams, that means faster investigations and fewer false alarms.
Key Features & Real-World Benefits
- Dual-channel design (8 MP + 4 MP) — get detailed identification and panoramic coverage simultaneously, reducing equipment and installation complexity.
- 8 MP resolution (3840 × 2160) — capture sharp facial and vehicle details for stronger evidence.
- DarkFighter + ColorVu low-light technology — maintain usable color images in extremely low light, minimizing nighttime guesswork.
- Hybrid IR and White Light (up to 120 m) — extend visibility in complete darkness without sacrificing clarity.
- 140 dB Wide Dynamic Range (WDR) — handle bright headlights and strong backlight without losing detail.
- License Plate Recognition (≥98% rate) — identify vehicles accurately in checkpoint and roadway scenarios.
- Face capture and comparison (up to 150,000 faces) — strengthen access control and investigative capabilities.
- Perimeter protection with human/vehicle filtering — reduce false alarms by focusing only on relevant targets.
- MicroSD storage up to 256 GB — enable edge recording for backup or standalone operation.
- IP67 & IK10 rated housing — withstand harsh weather and vandal attempts with confidence.
- PoE, 12 VDC, or 24 VAC power options — simplify installation in both new and retrofit projects.
What This Helps You Avoid
Without the right camera, security teams often struggle with incomplete footage—wide views without detail or zoomed shots without context. That leads to missed identifications, wasted time reviewing recordings, and unreliable alerts triggered by irrelevant movement. This model addresses that pain directly by combining panoramic awareness, deep-learning detection, and high-resolution detail in one device. The result is clearer evidence, fewer false alarms, and faster response times when incidents occur.
What’s in the Box
Product Support & Shipping Details
Product Support & Shipping Details
We move quickly so you don’t have to wait, place your order before 3pm EST and it ships out the same day, with everything else going out the next business day. Most customers see their package in about 3 business days, giving you a smooth, predictable delivery experience.
For Support you’re never on your own with us. if something comes up, our U.S.-based support team is here to help you troubleshoot, set up, or get answers fast. We make sure you always know exactly what to do next so your product keeps working the way you need it to.
30 Day Returns & Money Back Guarantee
30 Day Returns & Money Back Guarantee
If the product isn’t the right fit, no worries—our 30-day money-back guarantee gives you the space to try it without the pressure. You can return it within 30 days as long as it’s in its original condition. And to keep things simple, you can start the return right from your account, no hassle, no long back-and-forth.
Downloads
Product Manuals, data sheets.
Downloads
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
DS-1475ZJ-SUS, DS-1476ZJ-SU, DS-1275ZJ-S-SUS, DS-1475ZJ-Y, DS-1476ZJ-Y
Technical Specifications
Hikvision iDS-2CD8A86G0-XZS — 8 MP DeepinView Multi-sensor Bullet Camera
If you’re trying to cover a wide area but still need real, usable details when something happens, this dual-channel camera is built for that exact problem. Channel 1 delivers crisp 8 MP detail, while Channel 2 gives you a panoramic view—so you’re not forced to choose between “zoomed-in evidence” and “big-picture coverage.” Add DarkFighter + ColorVu low-light performance and smart deep-learning detection, and you get cleaner alerts and faster video review when time matters.
Ideal Applications (Common Uses)
- Perimeter coverage for warehouses, yards, and fences (line crossing / intrusion focus).
- Parking lots and entrances where you want both overview + identifiable detail.
- Retail storefronts and building exteriors needing smart alerts with fewer false triggers.
- Roadside or checkpoint-style areas where license plate capture and recognition is important.
- Sites that need durable outdoor protection (IP67) and vandal resistance (IK10).
Key Features
- Dual-channel design — get detail in Channel 1 and a panorama view in Channel 2, so you don’t miss context.
- 8 MP (Channel 1) + 4 MP (Channel 2) — sharper evidence where it counts, wider coverage where it helps most.
- DarkFighter + ColorVu low-light performance — clearer night footage so you’re not guessing in the dark.
- 140 dB WDR — handles strong backlight (headlights, sunlight, bright entrances) for more usable images.
- Hybrid supplemental light (IR + white light) — better nighttime visibility with smart control.
- Deep-learning functions — face capture, perimeter protection, multi-target recognition, and license plate recognition for more actionable alerts.
- H.265+ compression — saves bandwidth and storage without sacrificing video quality.
- Outdoor + vandal protection — IP67 and IK10 for real-world installations.
Model Overview
Image Sensor & Imaging
Lens & Field of View
Tele: D: 620.7 m, O: 246.3 m, R: 124.1 m, I: 62.1 m
Illuminator (Supplement Light)
Video Streaming & Compression
60 Hz: 24 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Channel 2: 50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480)
Channel 2: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480); 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Channel 2: 50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480)
Channel 2: 50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480)
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
Fourth stream: H.265/H.264/MJPEG
Fifth stream: H.265/H.264/MJPEG
Audio
1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound
Network, Security & Compatibility
Image Controls & Enhancements
Deep Learning Functions
Channel 2: Line crossing, intrusion, region entrance, region exiting; Support alarm triggering by specified target types (human and vehicle)
Interfaces, Storage & I/O
Events & Linkage
Power, Build & Environmental
12 VDC ± 20%, 1.90 A, max. 22.7 W
24 VAC ± 20%, 1.39 A, max. 22.3 W
PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.59 A to 0.44 A, max. 24.7 W
Approvals & Standards
Accessories Found (Optional Accessories Listed)
- DS-1475ZJ-SUS
- DS-1476ZJ-SUS
- DS-1275ZJ-S-SUS
- DS-1475ZJ-Y
- DS-1476ZJ-Y
Downloads
`
Frequently Asked Questions
Yes, this model features a dual-channel design. Channel 1 delivers up to 8 MP resolution (3840 × 2160), while Channel 2 provides up to 4 MP resolution (2560 × 1440) with a wider field of view. This means you get detailed identification from the main lens and broad situational awareness from the panoramic lens at the same time. Instead of installing two separate cameras, you gain both focused detail and full-scene coverage in a single unit.
The camera combines DarkFighter and ColorVu technologies for enhanced low-light imaging. Channel 1 supports color imaging down to 0.0005 Lux and Channel 2 down to 0.0003 Lux, with 0 Lux capability using built-in light or IR. It includes hybrid supplemental lighting (IR and white light) with a range of up to 120 m on Channel 1 and 30 m on Channel 2. This allows the camera to capture usable images even in extremely dark environments.
Yes, Channel 1 supports face capture and face comparison functions. It can detect up to 120 faces simultaneously and supports up to 10 face libraries with 30,000 faces per library, totaling 150,000 faces. The system also supports encrypted face libraries for added security. This makes it suitable for controlled access areas or environments requiring advanced identity management.
Yes, Channel 1 supports license plate recognition with a recognition rate of ≥98% under recommended conditions. It can manage blocklists and allowlists of up to 10,000 records. The camera also supports vehicle attribute detection, including vehicle type, color, and brand. This makes it effective for checkpoint scenarios and traffic monitoring applications.
Both channels support perimeter protection functions such as line crossing detection, intrusion detection, region entrance, and region exiting. Alarm triggering can be configured to respond specifically to human or vehicle targets. This targeted detection reduces false alarms caused by irrelevant movement. It provides more reliable alerts for critical boundary monitoring.
Yes, the camera is rated IP67 for water and dust resistance and IK10 for vandal resistance. It operates in temperatures from -30°C to 60°C (-22°F to 140°F). The housing is constructed from aluminum alloy for durability. It also includes a built-in heater and demist function to support performance in challenging weather conditions.
The camera includes a built-in memory card slot that supports microSD, microSDHC, and microSDXC cards up to 256 GB. This allows for edge storage directly on the device. In addition, video can be uploaded to FTP, NAS, or a memory card through linkage actions. These options provide flexibility for local and network-based storage strategies.
The main stream supports H.265+, H.265, H.264+, and H.264 compression formats. Additional streams support combinations of H.265, H.264, and MJPEG. The camera also supports scalable video coding (SVC) for H.264 and H.265 encoding. These options help balance image quality, bandwidth usage, and storage efficiency.
Yes, the camera supports mono sound and includes both audio input and output via 3.5 mm connectors. It supports multiple audio compression formats such as G.711, G.722.1, G.726, MP2L2, PCM, MP3, and AAC-LC. Sampling rates range from 8 kHz to 48 kHz. Environment noise filtering is also supported to help improve audio clarity.
The camera supports multiple power options, including 12 VDC, 24 VAC, and PoE (IEEE 802.3at, Type 2, Class 4). Maximum power consumption is approximately 24.7 W depending on the power source. This flexibility allows installers to integrate the camera into different infrastructure environments. It simplifies deployment in both new and retrofit installations.
