LTS 8CH DVR LTD8508M-ST (NO HARD DISK) Platinum Pro 5MP+2IP 6MP HD-TVI AHD CVI
LTS 8CH DVR LTD8508M-ST (NO HARD DISK) Platinum Pro 5MP+2IP 6MP HD-TVI AHD CVI
Out of stock
Description
Description
LTS 8CH DVR LTD8508M-ST (NO HARD DISK) Platinum Pro 5MP+2IP 6MP HD-TVI AHD CVI
This listing includes:
-  (1) HARD DRIVE OPTION: NO HARD DRIVE;2TB;4TB;8TB;10TB;12TB;16TB
- (1) DIGITAL VIDEO RECORDER: LTD8508M-ST
LTD8508M-ST  view data sheet
Turbo Smart HD-TVI DVR
HD-TVI DVR with H.265 Pro+, deep learning-based motion detection 2.0 for all analog channels
- H.264 / H.264+ / H.265 / H.265 Pro / H.265 Pro+ video compression
- HD-TVI / AHD / CVI / CVBS / IP video inputs
- Audio via coaxial cable
- Up to 16 IP camera inputs (up to 8 MP)
- Supports 2 x SATA HDDs up to 10 TB each
- MD 2.0 Compatible
Couldn't load pickup availability
Get $25 off when you spend $750 or more!
Shipping Details
Shipping Details
We move quickly so you don’t have to wait, place your order before 3pm EST and it ships out the same day, with everything else going out the next business day. Most customers see their package in about 3 business days, giving you a smooth, predictable delivery experience.
Product Support
Product Support
You’re never on your own with us. if something comes up, our U.S.-based support team is here to help you troubleshoot, set up, or get answers fast. We make sure you always know exactly what to do next so your product keeps working the way you need it to.
30 Day Returns & Money Back Guarantee
30 Day Returns & Money Back Guarantee
If the product isn’t the right fit, no worries—our 30-day money-back guarantee gives you the space to try it without the pressure. You can return it within 30 days as long as it’s in its original condition. And to keep things simple, you can start the return right from your account, no hassle, no long back-and-forth.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Technical Specifications
Data sheet PDF
Product Description
Turbo Smart HD-TVI DVR
HD-TVI DVR with H.265 Pro+, deep learning-based motion detection 2.0 for all analog channels
- H.264 / H.264+ / H.265 / H.265 Pro / H.265 Pro+ video compression
- HD-TVI / AHD / CVI / CVBS / IP video inputs
- Audio via coaxial cable
- Up to 16 IP camera inputs (up to 8 MP)
- Supports 2 x SATA HDDs up to 10 TB each
- MD 2.0 Compatible
Specifications
Model LTD8508M-ST
Motion Detection 2.0?
Human / vehicle analysis
Deep learning-based motion detection 2.0 is enabled by default for all analog
channels. It can classify human and vehicle targets and vastly reduce false
alarms caused by objects like leaves, animals and light changes.
Quick search by object or event type is supported.
Perimeter Protection?
Human / vehicle analysis Up to 4 channels
Recording
Video compression H.264, H.264+, H.265, H.265 Pro, H.265 Pro+
Encoding resolution
Main stream:
8 MP @ 8 fps / 5 MP @ 12 fps / 4 MP @ 15 fps / 3 MP @ 18 fps
1080p / 720p /WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N)
Sub-stream:
WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps to 10 Mbps
Dual stream Supported
Stream type Video, Video & Audio
Audio compression G.711 u
Audio bit rate 64 Kbps
Video and Audio
IP video input2
4 channels (up to 12)
Enhanced IP mode on:
8 channels (up to 16), each up to 4 Mbps
Up to 8 MP resolution
Supports H.264 / H.264+ / H.265 / H.265+ IP cameras
Analog video input
8 channels
BNC interface (1.0 Vp-p, 75 ?), supporting coaxitron connection
HDTVI input 8 5, 4, and 3 MP; 1080p @ 30 fps or 25 fps; 720p @ 60, 50, 30 or 25 fps
AHD input 5 &4 MP; 1080p @ 25 or 30 fps; 720p @ 25 or 30 fps
HDCVI input 4 MP; 1080p @ 25 or 30 fps; 720p @ 25 or 30 fps
CVBS input PAL/NTSC
CVBS output
1 channel, BNC (1.0 Vp-p, 75 ?)
Resolution: PAL: 704 ? 576, NTSC: 704 ? 480
VGA output 1 channel, 1920 ? 1080 @ 60 Hz
1280 ? 1024 @ 60 Hz
1280 ? 720 @ 60 Hz
1024 ? 768 @ 60 Hz
HDMI/VGA simultaneous output
HDMI output 1-channel, 4K (3840 ? 2160) @ 30 Hz
2K (2560 ? 1440) @ 60 Hz
1920 ? 1080 @ 60 Hz
1280 ? 1024 @ 60 Hz
1280 ? 720 @ 60 Hz
1024 ? 768 @ 60 Hz
HDMI / VGA simultaneous output
Audio input
1 ch, RCA (2.0 Vp-p, 1 K?)
8 channels via coaxial cable
Audio output 1 ch, RCA (Linear, 1 K?)
Two-way audio 1 ch, RCA (2.0 Vp-p, 1 K?) (using the audio input)
Synchronous playback 8 channels
Network
Remote connections 64
Network protocols
TCP/IP, PPPoE, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,
ONVIF
Network interface 1 x RJ45 10/100/1000 Mbps self-adaptive Ethernet interface
Wi-Fi Connectable to Wi-Fi network by Wi-Fi dongle through USB interface
Auxiliary interface
SATA 2 x SATA interfaces
Capacity Up to 10 TB storage capacity for each HDD
Serial interface RS-485 (half-duplex)
USB interface
Front panel: 1 ? USB 2.0
Rear panel: 1 ? USB 3.0
Alarm in/out N/A
General
Power supply 12 VDC, 2.8 A
Consumption
(without HDD) ? 15 W
Operating temperature 14? to 131? F (-10? to 55? C)
Operating humidity 10% to 90%
Dimensions (W ? D ? H) 15.0 ? 12.6 ? 1.9 in. (380 ? 320 ? 48 mm)
Weight (without HDD) ? 13.9 lbs (78 kg)
