Audio / Video Input

IP Video Input

32 channels

Two-way Audio Input

1 channel, RCA

Network

Incoming Bandwidth

160 Mbps

Outgoing Bandwidth

64 Mbps

Remote Users

128

Protocols

P2P, UPnP, NTP, DHCP, PPPoE

Audio / Video Output

HDMI / VGA Output

HDMI: 4K (3840 x 2160 @ 30 fps), 1920 x 1080 @ 60 fps, 1920 x 1080 @ 50 fps, 1600 x 1200 @ 60 fps, 1280 x 1024 @ 60 fps, 1280 x 720 @ 60 fps, 1024 x 768 @ 60 fps

VGA: 1920 x 1080 @ 60 fps, 1920 x 1080 @ 50 fps, 1280 x 1024 @ 60 fps, 1280 x 720 @ 60 fps, 1024 x 768 @ 60 fps

Recording Resolutions

8 / 6 / 5 / 4 / 3 MP; 1080p / 960p / 720p; D1 / 2CIF / CIF

Audio Output

1 ch, RCA

Synchronous Playback

32 ch

Corridor Mode Screen

3 / 4 / 5 / 7 / 9 / 10 / 12 / 16 / 32

Decoding

Decoding format

Ultra265 / H.265 / H.264

Live View / Playback

8 / 6 / 5 / 4 / 3 MP; 1080p / 960p / 720p; D1 / 2CIF / CIF

Capacity

2 x 4K @ 30 fps, 4 x 4 MP @ 30 fps, 5 x 3 MP @ 30 fps, 8 x 1080p @ 30 fps, 16 x 720p @ 30 fps, 32 x D1 @ 30 fps

Hard Drives

SATA

4 x SATA interfaces

Capacity

Up to 14 TB for each disk

External Interface

Network Interface

1 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet Interface

USB Interface

Front panel: 1 x USB 2.0
Rear panel: 1 x USB 3.0

Serial Interface

1 x RS485

Alarm In

16 channels

Alarm Out

4 channels

PoE

Interface

16 independent 100 Mbps PoE network interfaces

Max. Power

Max 30 W for single port

Max 240 W in total

Supported Standard

IEEE 802.3af/at

General

Power Supply
(without HDD)

100 ~ 240 V AC

Power Consumption: ? 15 W

Operating Environment

14? to 131? F (-10? to 55? C), Humidity ? 90% RH (non-condensing)

Dimensions
(W x D x H)

15.7 x 14.2 x 2.9" (400 x 362 x 74 mm)

Weight
(without HDD)

? 5.29 lb (5 kg)
